FEATURES

Cabinet
• Steel cabinet with two-colour high gloss powder coat finish
• Doors out of steel and strong polysterol material, two-colour high gloss paint
• Design and control elements made of chromium-plated zinc cast moulding
• Modular construction for easy maintenance
• 2 wheels and strap for transport Cooling unit
• Sealed system with R134a refrigerant (free of CFCs)
• Adjustable from 2°C (35°F) to 15°C (59°F) Control elements
• 5-digit LED display
• Selection lever with easy LH/RH movement
• Bottle opener with crown cork receptacle
• Delivery control to avoid collision of cans and bottles in the delivery compartment Electronic
• Microprocessor control unit
• Vend and cash counter
• Password lock for different settings
• MDB or Executive interface Payment system
• Coin acceptor with or without change
• Machine can also be operated without coin system in free vend mode


Bottle /Can Dimensions
• Diameter min. 52mm (2"), max. 66mm (2 1/2")
• Height min. 92mm (3 /5/8"), max.306mm (12")
Capacity per column / total
• 0.25l cans 40 / 80
• 0.33l cans 32 / 64
• 0.50l cans 16 / 32
• 0.33l glass bottles 16 / 32
• 0.50l PET bottles 16 / 32


Power Supply
• Power consumption 250watts
• 230volts, 10amps, 50cps
• Other voltages upon request
• Extra-low voltage supply for internal
functions


Dimensions
• Height 146.0 cm - 57 1/2"
• Width 41.0 cm - 16"
• Depth 56.0 cm (cabinet incl. door) - 22"
• Weight approx. 117 kg - 257 1/2 lbs
